PCJ-2 - Swing CO2 Jet for Dynamic EffectsPCJ-2 - Swing CO2 Jet for Dynamic Effects
Rotating CO2 blasts for high-energy shows and immersive performances.The PrimeFX Aqua is designed for water-adjacent environments, perfect for pool parties and water shows.
Engineered for Excellence
See It In Action
Experience the power of the PCJ-2 in real-world applications.
Technical Specifications
Power & Electrical
- Input Voltage: AC 220-240 V, 50/60 Hz
- Total Power Consumption: 25 W
- Operating Current: 0.1 A
- Connector: Lockable PowerCon
- Fuse Rating: 2 A, 250 V
Heating System
- Heater Type: Fast Coil Heater
- Heat-Up Time: Approx. 50 sec
Tank & Fluid
- Tank Capacity: 3 L
- Compatible Fluids: PRO-C / PRO-J
Output
- Max CO2 Plume Height: Approx. 8 m
- Adjustable Output Angle: 0°-90°
- CO2 Consumption: Approx. 2 kg/sec
Control
- Manual: 7-segment digital display
- Wired Control: Optional
- DMX512: 1 DMX Channel, 3-pin XLR
Features
- Aerodynamic fog dispersion (no fan required)
- Rotational molded composite body
- Low water and overheat protection
- Clear water level display
- Multi-level output control
- Anti-drip water outlet
Consumables
- Liquid CO2 Cylinder (not included)
Weight & Dimensions
- Net Weight: 4.5 kg
- Gross Weight: 4.9 kg
- Machine Size: 285 x 170 x 314 mm
- Packing Size: 335 x 330 x 220 mm
